Rotary Quadruplex - 4 UP & 2 UP

Code : SQ Series

Brand name : Solpac

Price : Contact us

Request a quote

Hotline: 098 556 1557

Feature

- PLC control with touch screen operation
- Long durability welded steel frame
- Washdown structure (IP65)
- Easy access rotational touch screen
- Production parameter memory incl. gripper size, machine speed, sealing temperature, filling volumne
- Pouch presence detection - no filling, no sealing
- De-aeration with wire guide or push bars
- Steam/ gas flush
- Automatic deoxidizer feeding station
- Product filling - can be integrated with weighing scales/auger filler/ cup conveyor
- Two step sealing process guarantees clean seal, cooling station for liquid Product
- Encoder controlled inkjet printer for accurate printing position at high speed

Optional

- Filling options

- Product conveyor options

Specifications

Max speed per minute: 200

Bag gripping range (mm): 75-110

Max bag length (mm): 320

Electrical requirements: 220-430V, 3 phase, 50/60Hz

Compressed air: 900 L/min @ 6 bar
